Steel Tubes India has pride in providing a whole range of high-class, customizable and innovative Stainless Steel ERW Pipes and Tubes using state-of-art technology. Our range includes Stainless Steel ERW Pipes and Tubes, Stainless Steel Seamless pipes & Tubes, Carbon Steel Seamless Pipes & Tubes and Alloy Steel Seamless Pipes & Tubes. For more than five decades, Steel Tubes India has been serving the needs of the oil and gas industries, automotive, shipbuilding, power plants. All the supply records for most of the severe environment of Stainless Steel ERW Pipes and Tubes & pipe line indicate that Steel Tubes India is the leader in line pipe technologies.
We have been supplying high quality Stainless Steel ERW Pipes and Tubes with most advance technology and with most reliable quality. We place importance not just on managing material sales, but also on 'before' and 'after service'. We are winner of All India Award for Export Excellence for 2006-07, 2007-08, 2008-09, 2009-10, 2010-11.
Stainless steel ERW pipes and ERW pipes are fabricated in different alloys of ASTM / ASME SA 312 GR. TP 304 , 304L , 304H, 309S ,309H , 310S, 310H , 316 , 316L, 316H , 316Ti , 317 , 317L , 321 , 321H , 347 , 347 H , 904L ASTM / ASME SA 358 CL 1 & CL 3 GR . 304 , 304L , 304H, 309S ,309H , 310S, 316 , 316H , 321 , 321H , 347 and others. Our comprehensive range includes welded stainless steel pipes, ERW alloy steel pipes, welded steel pipes and many more. We produce using ace quality of steel and alloy to retain their durability for longer period.
STAINLESS STEEL ERW / WELDED PIPES AND TUBES RANGE :
15 NB UP TO 600 NB IN SCH 5S , 10S ,10, 20 , 40S , 40 , STD , 60 , 80S , 80 , XS , 100 , 120 , 140 , 160 & XXS
STAINLESS STEEL ERW / WELDED PIPES AND TUBES TYPE
ERW / WELDED
STAINLESS STEEL ERW / WELDED PIPES AND TUBES FORM
ROUND, SQUARE, RECTANGULAR, HYDRAULIC ETC.
STAINLESS STEEL ERW / WELDED PIPES AND TUBES LENGTH
SINGLE RANDOM, DOUBLE RANDOM & CUT LENGTH
STAINLESS STEEL ERW / WELDED PIPES AND TUBES END
PLAIN END, BEVELLED END, TREADED
STAINLESS STEEL ERW / WELDED PIPES AND TUBES VALUE ADDED SERVICES
| Pipe Type | NB Sizes | Sch 5 | Sch 10 | Sch 40 | Sch 80 | Sch 160 |
|---|---|---|---|---|---|---|
| Stainless Steel ERW Pipes and Tubes | 1/8″ |
 |
|
|
|
|
| Stainless Steel ERW Pipes and Tubes | 1/4″ |
|
|
|
|
|
| Stainless Steel ERW Pipes and Tubes | 3/8″ |
|
|
|
|
|
| Stainless Steel ERW Pipes and Tubes | 1/2″ |
|
|
|
|
|
| Stainless Steel ERW Pipes and Tubes | 3/4″ |
|
|
|
|
|
| Stainless Steel ERW Pipes and Tubes | 1″ |
|
|
|
|
|
| Stainless Steel ERW Pipes and Tubes | 1 1/4″ |
|
|
|
|
|
| Stainless Steel ERW Pipes and Tubes | 1 1/2″ |
|
|
|
|
|
| Stainless Steel ERW Pipes and Tubes | 2″ |
|
|
|
|
|
| Stainless Steel ERW Pipes and Tubes | 2 1/2″ |
|
|
|
|
|
| Stainless Steel ERW Pipes and Tubes | 3″ |
|
|
|
|
|
| Stainless Steel ERW Pipes and Tubes | 4″ |
|
|
|
|
|
| Stainless Steel ERW Pipes and Tubes | 5″ |
|
|
|
|
|
| Stainless Steel ERW Pipes and Tubes | 6″ |
|
|
|
|
For stainless steel ERW pipes specification click on below links:
Welded Tubing Dimensional Chart |
|||
Outside Diameter |
Outside Diameter Tolerance |
Inside Diameter Tolerance |
Wall Tolerance |
Up to inclusive 1/2" |
+.003" -.003" |
+.003" -.003" |
+5% -5% |
>1/2", but less than 1" |
+.004" -.004" |
+.004" -.004" |
+5% -5% |
1", but less than 1 1/2" |
+.005" -.005" |
+.005" -.005" |
+5% -5% |
1 1/2", but less than 2" |
+.006" -.006" |
+.006" -.006" |
+5% -5% |
2", but less than 2 1/2" |
+.007" -.007" |
+.007" -.007" |
+5% -5% |
2 1/2" to 3 1/2" |
+.010" -.010" |
+.010" -.010" |
+5% -5% |
At Steel Tubes India, we proudly provide quality Stainless Steel ERW Pipes and Tubes to the following industries:
|
|
Stainless Steel ERW Pipes and Tubes Packaging at Steel Tubes India Factory |
Stainless Steel ERW Pipes and Tubes Packaging at Steel Tubes India Factory |
| Packaging Details: | There are probably hundreds of different methods for packing a pipe, and most of them have merit, but there are two principles that are vital for any method to work prevent rusting and Sea transportation security. Our Stainless Steel ERW Pipes and Tubes packing can meet any needs of the customers. Stainless Steel ERW Pipes and Tubes Bundle packing |
| Delivery Detail: | 7-15 days |
| Standards | 904L |
|---|---|
| UNS | N08904 |
| Werkstoff Nr. | 1.4539 |
| Density | 8.05 g/cm3 |
|---|---|
| Melting Point | 1350 °C (2460 °F) |
| Tensile Strength | Psi – 71000 , MPa – 490 |
| Yield Strength (0.2%Offset) | Psi – 32000 , MPa – 220 |
| Elongation | 35 % |
| Alloy 904L | |
|---|---|
| Ni | 23 – 28 |
| Mo | 4 – 5 |
| Cr | 19 – 23 |
| Cu | 1 – 2 |
| C | 0.02 max |
| Mn | 2.0 max |
| Si | 1.0 max |
| P | 0.045 max |
| S | 0.035 max |
Welded Pipe (304)
